Powering Your Web Applications with Tengine/Nginx on Alibaba Cloud ECS

# user  op; # Best practice: run Nginx worker processes as a non-privileged user.
worker_processes  1; # Number of worker processes, often set to the number of CPU cores.

#error_log  logs/error.log;
#error_log  logs/error.log  notice;
#error_log  logs/error.log  info;
#error_log  "pipe:rollback logs/error_log interval=1d baknum=7 maxsize=2G"; # Advanced logging with rotation.
error_log  logs/error.log warn; # Set error log level to 'warn'.

pid        /opt/tengine/logs/nginx.pid; # Path to the PID file.

worker_rlimit_nofile 51200; # Maximum number of open files per worker process.

events {
    multi_accept on; # Workers accept all new connections at once.
    use epoll; # Use epoll for network I/O on Linux for better performance.
    worker_connections  51200; # Maximum number of simultaneous connections per worker.
}


http {
    server_tokens off; # Disable emitting Nginx version on error pages and in "Server" header.
    add_header X-Frame-Options SAMEORIGIN; # Prevents clickjacking.
    add_header X-Content-Type-Options nosniff; # Prevents MIME-sniffing.
    add_header X-XSS-Protection "1; mode=block"; # Enables XSS filtering.
    more_clear_headers 'Server'; # Completely removes the 'Server' header (Tengine specific or via module).

    include       mime.types; # Includes file extension to MIME type mappings.
    default_type  application/octet-stream; # Default MIME type.

    sendfile    on; # Enables sendfile() system call for faster static file serving.
    send_timeout  30; # Timeout for transmitting a response to the client.
    # fastcgi_buffers 8 128k;
    keepalive_timeout  30; # Timeout during which a keep-alive client connection will stay open.

    # server_names_hash_bucket_size 128;
    client_header_buffer_size 32k; # Buffer size for reading client request headers.
    large_client_header_buffers 4 32k; # Max number and size of buffers for large client request headers.
    client_max_body_size 8m; # Maximum allowed size of the client request body.
    client_body_buffer_size 512k; # Buffer size for reading client request body.

    # Proxy settings (commented out but good to know for reverse proxy setups)
    # proxy_connect_timeout 5;
    # proxy_read_timeout 30;
    # proxy_send_timeout 5;
    # proxy_buffer_size 16k;
    # proxy_buffers 4 64k;
    # proxy_busy_buffers_size 128k;
    # proxy_temp_file_write_size 128k;

    gzip  on; # Enables gzip compression.
    gzip_proxied any; # Compress data even for proxied requests.
    gzip_min_length  1k; # Minimum response length to gzip.
    gzip_buffers     4 16k; # Number and size of buffers for compression.
    gzip_http_version 1.1; # Gzip for HTTP/1.1 requests.
    gzip_comp_level 6; # Compression level (1-9).
    gzip_types text/plain application/json application/javascript application/x-javascript text/css application/xml text/javascript; # MIME types to compress.
    gzip_disable "MSIE [1-6]\."; # Disable gzip for old IE versions.
    gzip_vary on; # Adds "Vary: Accept-Encoding" header.

    charset utf-8; # Default charset.
    charset_types *; # Apply charset to all content types.

    # Default server block
    server {
      listen       80; # Listen on port 80 for IPv4.
      server_name  localhost; # Server name (can be IP or domain).

      location / {
        root   /opt/applications; # Root directory for requests to this location.
        index  index.html index.htm; # Default files to serve.
      }
    }

   # Include virtual host configurations from a separate directory
   # This is a best practice for managing multiple sites.
   include sites/xxx.domain.com.conf; # Note: .conf extension is a common convention
   include sites/xxx.domain2.com.conf;
   include sites/xxx.domain3.com.conf;
}

upstream my_hyperse_node {
  server  127.0.0.1:7001;
}
server {
  listen               80;
  access_log off;
  server_name          my.hyperse.net;
  return 301           https://my.hyperse.net$request_uri;
}
server {
  if ($host ~* ^www\.) {
    rewrite ^ $scheme://$host$request_uri permanent;
  }
  listen               443 ssl;
  server_name          oss.hyperse.net;
  ssl_certificate      sslkey/hyperse/www_hyperse_net.crt;
  ssl_certificate_key  sslkey/hyperse/www_hyperse_net.key;
  ssl_session_cache    shared:SSL:1m;
  ssl_session_timeout  5m;
  ssl_ciphers ECDHE-RSA-AES128-GCM-SHA256:ECDHE:ECDH:AES:HIGH:!NULL:!aNULL:!MD5:!ADH:!RC4;
  ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
  ssl_prefer_server_ciphers  on;
  access_log off;

  location ~* \.(tpl|inc|cfg|less|scss)$ {
    deny all;
  }

  location ~ /\. {
    deny all;
    log_not_found off;
  }

  location = /robots.txt {
    alias /opt/applications/robots/disallow.txt;
  }

  location /favicon.ico {
    alias /opt/applications/favicon-oss/favicon.ico;
  }

  location / {
    proxy_set_header Host $http_host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-Host $host:$server_port;
    proxy_set_header X-Forwarded-Server $host;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header X-NginX-Proxy true;
    proxy_pass http://my_hyperse_node;
    proxy_redirect off;
  }
}

sudo systemctl status nginx

● nginx.service - The nginx HTTP and reverse proxy server
   Loaded: loaded (/usr/lib/systemd/system/nginx.service; enabled; vendor preset: enabled)
   Active: active (running) since Sun 2024-06-09 09:20:20 CST; 1 months 12 days ago
 Main PID: 2551738 (nginx) # This is the master process
    Tasks: 2 (limit: 100494)
   Memory: 31.7M
   CGroup: /system.slice/nginx.service
           ├─2551738 nginx: master process /opt/tengine/sbin/nginx -c /opt/tengine/conf/nginx.conf
           └─2551739 nginx: worker process

sudo systemctl restart nginx.service

sudo systemctl reload nginx.service

sudo /opt/tengine/sbin/nginx -t -c /opt/tengine/conf/nginx.conf
# Or if nginx is in your PATH and aliased to tengine's binary
# sudo nginx -t

systemctl list-units --type=service --state=running

systemctl list-units --type=service
